Infineon BFR 182 E6327 RF バイポーラ 小信号 NPN シリコン RF トランジスタ
生産者: Infineon Model: BFR 182 E6327 - 連絡先
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Width: 1.3 mm
Height: 1 mm
Length: 2.9 mm
Technology: Si
Unit Weight: 8 mg
Configuration: Single
Qualification: AEC-Q100
Mounting Style: SMD/SMT
Transistor Type: Bipolar
Operating Frequency: 8 GHz
Transistor Polarity: NPN
Pd - Power Dissipation: 250 mW
DC Current Gain hFE Max: 70 at 10 mA at 8 V
Gain Bandwidth Product fT: 8000 MHz
Emitter- Base Voltage VEBO: 2 V
Collector- Base Voltage VCBO: 20 V
Continuous Collector Current: 35 mA
Maximum DC Collector Current: 35 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 65 C
DC Collector/Base Gain hfe Min: 70
Collector- Emitter Voltage VCEO Max: 12 V
