Yokogawa AQ1301 イーサネットマルチフィールドテスタ（1GB）

Optical connector: Universal connector (1.25 mm dia.), SC, FC

Measurement wavelength: 850/1300/1310/1490/1550/1625/1650 nm

Measurement power range: -70 dBm to +10 dBm (CW), -70 dBm to +7 dBm (CHOP)

Measurement accuracy: ±5% (Ta=23±2°C, condition: 1310 nm, -10 dBm, SM fiber)

Display: 5.7-inch color TFT LCD display

AC power: Rated voltage: 100 to 120/200 to 240 VAC; Rated frequency: 50/60Hz

Battery power supply: Operating time: Approx. 2 hour

Charging time: Approx. 5 hours (at 23°C, power OFF)

Dimensions: 217.5 (W) 157 (H) 74 (D) mm (excluding protrusions)

Weight: Approx. 1.3 kg including battery pack

Accessories: Standard CD-ROM (Setup software, User’s Manual), Operation Guide, battery pack, AC adapter, power cable, hand belt.
