Measuring range and Accuracy (at23℃±5℃)
Range Measuring range Resolution Measuring current Accuracy
200mΩ 10μΩ~199.99mΩ 10μΩ DC 100mA within ±0.05% of rdg ±3digit
2Ω 100μΩ~ 1.9999Ω 100μΩ DC 10mA within ±0.05% of rdg ±3digit
20Ω 1mΩ~ 19.999Ω 1mΩ DC 10mA within ±0.025% of rdg ±3digit
200Ω 10mΩ~ 199.99Ω 10mΩ DC 5mA within ±0.025% of rdg ±3digit
2kΩ 100mΩ~ 1.9999kΩ 100mΩ DC 5mA within ±0.025% of rdg ±3digit
20kΩ 1Ω~ 19.999kΩ 1Ω DC 500μA within ±0.025% of rdg ±3digit
200kΩ 10Ω~ 199.99kΩ 10Ω DC 50μA within ±0.025% of rdg ±3digit
2MΩ 100Ω~1.9999MΩ 100Ω DC 5μA within ±0.025% of rdg ±3digit
20MΩ 1kΩ~19.999MΩ 1kΩ DC 0.5μA within ±0.05% of rdg ±3digit
Measuring method: 4-terminal measurement
Sampling time [Free running mode]: 10.5 times/sec.
[Remote start mode] 80msec. (Power 50Hz), 66.7msec. (Power 60Hz)
Comparator set range: Both upper and lower limit 4½ digit (19999)
Indication of comparator's comparison result: LED indication LO/GO/HI and buzzer
Control signal
comparison output (LO/GO/HI):open collector max.80V, 100mA
completion of the measurement signal (EOC):open collector max.80V, 100mA
measured value in BCD parallel (fan out 2)
print command (fan out 2)
range (fan out 2)
Power supply: AC100V~240V selectable, 50/60Hz, about 15VA
Outer dimension: about 260 (W) ×90 (H) ×250 (D) mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 2.6kg
