Measuring range and Accuracy (at23*C±5*C) *D<0.5 parallel equivalent circuit
Range/ Measuring range/ Measuring voltage/ Accuracy
0/ 10pF~ 99.9pF/ about 1V (r.m.s.)/ within ±0.25%±0.25pF±1digit
1/ 100pF~ 990pF/ about 1V (r.m.s.)/ within ±0.25%±0.25pF±1digit
2/ 1nF~ 9.99nF/ about 1V (r.m.s.)/ within ±0.25%±0.25pF±1digit
3/ 10nF~ 99.9nF/ about 1V (r.m.s.)/ within ±0.25%±0.25pF±1digit
4/ 100nF~ 999nF/ about 1V (r.m.s.)/ within ±0.25%±0.25pF±1digit
5/ 1μF~9.99μF/ about 1V (r.m.s.)/ within ±0.25%±0.25pF±1digit
Test signal: within 1kHz ±0.1%, SINE wave
C offset range: about 10pF
Decision time + measurement: [Remote start mode] about 10msec.
Sampling time: [Free running mode] 50 times/sec.
Measured value display range: ±99.9%
External bias: max.DC25V
Comparator set range:
upper limit:+0.0%~+99.9%
lower limit:-0.0%~-99.9%
Indication of comparator's comparison result: LED indication -NG, GO, +NG and buzzer
Control signal:
Remote start input:"L" [OV] →"H" [DC12V] start
Remote hold input:Open and "H" [DC12V]
:Free run/"L" [OV] :Hold
comparison output [-NG/GO/+NG]:open collector:max.50V, 100mA
end of comparison output [EOC]:open collector:max.50V, 100mA
BCD parallel output of measured value [BCD] :fan out 2
Printing command signal:fan out 2
Operation condition [Temp.]: +5*C~+40*C [Humidity] less than 85%
Power supply: AC100V~240V selectable, 50/60Hz, about 20VA
Outer dimension: about 260(W)×90(H)×250(D)mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 2.6kg
