- Temperature Range: 250 ~ 1600°C
- Optics:
Standard lens: 500 ~ 9000 mm
Close-up lens: 250 ~ 500 mm
- Spectral Ranges: 1.45 ~ 1.8 μm
- Resolution:
LED inside: 1°C/°F
LED outside: 0.1° up to 1000°C/°F, after this: 1°;
LCD: 0.1°C/°F
- Emissivity ε: Adjustable 10 ~ 100% in 0.1% steps
- Measurement Uncertainty (ε = 1, Tamb. = 23 °C): 0.4% of reading +1°C
- Repeatability (ε = 1, Tamb. = 23 °C): 0.1% of reading or 0.8°C (the larger value is valid)
- Temperature Coefficient: 0.01% / K (Tamb.=23°C) of reading
Optical Specifications
- Sighting: Optimized through-lens view finder with dioptry correction -2.5 to +3 dpt, indication circle for measuring spot
- Optics:
Achromatic, adjustable from a=500 to 9000 mm (with close-up lens: a=250 to 500 mm)
Effective lens aperture diameter D: 20 mm (distance ∞) to 25 mm (distance 500 mm)
View magnification: 3 x, angle of view: 10°
- Distance Ratio: min 310:1 (1.6 mm)
Environmental
- Protection Class: IP52 (housing, exclude handle with battery case), IP40 (handle)
- Ambient Temperature: 0 ~ 50°C (32 ~ 122°F)
- Storage Temperature: -10 ~ 65°C (14 ~ 149°F)
- Relative Humidity: Non-condensing conditions
- Weight: 1.2 kg with batteries
- Housing: Stainless steel
- Dimensions (L x W x H): 210 mm x 75 mm x 175 mm (8.27" x 2.95" x 6.89")
- Housing: Aluminum (housing), Polyamide (handle)
- CE Label: According to EU directives about electromagnetical immunity
Electrical:
- Power Supply: 6 x 1.5 V alkali-manganese IEC LR6 or 6 x 1.2 V rechargeable batteries
(uninterrupted operation time approx. 35 hours with alkali-manganese batteries)
Communication
- Serial Interface: USB 2.0 (supplies the instrument when connected, but without battery charging function)
- Response Time t90: 1 ms
- Data Storage: 4000 values, storage of: measurement value, date, time, parameters, emissivity, temperature unit
- Thread for Tripod: 3/8”
- Scope of Delivery: Pyrometer, video grabber, video cable, PC adjustment and evaluation software InfraWin, works certificate, and operating instructions.
