Input Power
- Source Voltage: 400 or 480 VRMS ±10%, 3φ
- Source Frequency: 47 ~ 63 Hz
- Source Current: 280A at 480 VAC input low line and 180 kW output 340A at 400 VAC input low line and 180 kW output
- Efficiency at Full Power: ≥ 90% typical
Output Power
- Max Power: 180 kW (270 kVA)
- Regulation Modes: Power, current, or voltage
- Frequency: 40 ~ 60 kHz typical at full power, up to 100 kHz at minimum power
- Maximum Current: 700ARMS output at lowest tap
- Maximum Voltage: 1460 V
- Stored (Arc) Energy: 1 mJ per kW
Communications: Analog, Profibus, RS-232, 422, 485
Cooling
- Medium: air and water
- Water Inlet Temperature: +10 ~ +40°C (+50 ~ +104°F)
- Operating Temperature: +5 ~ +40°C (+41 ~ +104°F)
- Relative Humidity: 10 ~ 85%, non-condensing, +2 ~ +25 gpm3
- Air Pressure: 80 ~ 106 kPa (800 ~ 1060 mbar); ~2000 m (6562') above sea level
- Size: 76.84 cm (30.25"); 152.4 cm (60"); 8.26 cm (3.25"); 213.36 (84")
- Weight: 1180 kg (2601 lb)
