Withstanding voltage
• Output voltage:
Range: (300 ~ 3000) VAC; Step: 10V
Accuracy: ± (2.5%x setting +10V); Distortion: <3%
• Output frequency:50Hz/60Hz; Accuracy: ±0.1Hz
• Actual capacity: ≥ 90%
• Breakdown current:
Range: (0.10~20.00) mA
Accuracy: ± (2.5%x reading +5 counts)
• Duration: Range: (1~99) s; Accuracy: ± (1 %x setting +0.1s)
• Arc: Set to 0, (1.00~10.00) mA, 0: Arc Off
Insulation Resistance
• Output voltage:
Range: (200 ~ 1000) V DC; Step: 5V
Accuracy: ± (3%x setting +5V)
• Ripple coefficient: <5%
• Resistance measurement:
Range: (1.0 ~ 99.9) M Ω, (100 ~500) M Ω
Accuracy: ± (3%x reading +5 counts), ≤200M Ω; ± (5%x reading +8 counts), >200M Ω
• Duration: Range: (1~99) s; Accuracy: ± (1 %x setting +0.1s)
Impulse
• Pulse voltage: Range: (200~3000) V; Step: 10V; Accuracy: ± (3%x setting +10V)
• Storage capacitance: Standard capacitance: 0.022 μF
• Wavefront time: ≤0.5 μs
• Waveform acquisition:
Frequency: 5kHz~40MHz, 13-level adjustable.
Resolution: 8-bit AD
Storage: 1k bytes.
Multiple tests: (1 ~ 10) times continuous
• Waveform parameter:
Area, difference area, range: (0 ~ 99)%
Resolution: 0.1%; Accuracy: ±3.0%
Resistance
• Resistance measurement:
Range: 0.1/ 2/20/200/2k/20k, unit: Ω
Accuracy: ±(0.3%x reading +3 counts) (temperature compensation off)
• Temperature measurement: Range: (0.0~60.0)°C; Accuracy: ±0.5°C
Field Direction
Magnetic field direction: Forward/Reverse/Stop
Anti-embedded
Anti-embedded test: Normal/Anti-embedded
Weight: 35 kg (single machine)
Dimension: 440(W)x265(H)x550(D)
