Force (max.) (N): 5
Length/Stroke (max.) (mm ): 405
Speed (max.)( mm/min ): 900
Resolution - Force (N ): 0.0005
Accuracy - Force (% (Mw. DIN ISO 7500-1) ): 0.5
Resolution - Length( mm ): 0.001
Accuracy - Length( mm): 0.01
Resolution - Speed( mm/min): 1
Accuracy - Speed (% (Vmax)): 0.1
Measuring frequency (selectable)( Hz 1): 00 | 1000
Measuring frequency - filtered (AV) (Hz ): 100
Working space - depth (mm): 115
Working space - hight( mm): 400 - 640
Adapter for grips (Thread ): M4
Power supply V AC (50...60Hz)( 85 - 264):
Power consumption (A @ 230 V AC): 1.8
Operator panel (Type): 10.4" Color TFT / Touch PCAP
2 USB interfaces( Type ): USB 2.0
Ethernet (socket) (Type ): 100 (RJ45 socket)
2 Digital inputs (optocoupler) (Type ): 5V Pull-Up
3 Digital outputs (Type ): 24 V Push-Pull
2 Analog IN (A/D converter) (Type ): 0-20mA (12-Bit) / 0-10V (12-Bit)
Service port (Type ): D-Sub. 9-P
Temperatur range - operation( °C ): 10-35
Adm. temperature - transp./stocking( °C ): -10-60
Dimension (LxWxH) (mm ): 560 x 300 x 910
Weight( kg ): 24.5
