AMETEK CTS PMR 6069 RF Power Meter (9 kHz ~ 6 GHz; version R)

Frequency Range: 9 kHz to 6 GHz

Linear Measurement Range: -45 dBm to +20 dBm

Max. Input (No Damage): +23 dBm

Input Return Loss: >20 dB (<4 GHz), >17 dB (4–6 GHz)

Connector Type: N male, 50 Ω

Accuracy (15–30°C): <0.5 dB, typ. <0.3 dB

Accuracy (Extended Temp) (5–45°C): <1 dB, typ. <0.5 dB (0–45°C)

Number of Averages: 1 to 10,000

Supply Current: ≤250 mA at 5 V

Supply Voltage Range: 4.7 V – 9 V

Environmental Condition:

Classification: Indoor use only

Operating Temperature: 0°C to +25°C

Storage and Transport Temperature: -10°C to +50°C

Relative Humidity: up to 90% (no moisture condition)

Mechanical Specifications:

Size (L x H x D): 111 mm x 27 mm x 46 mm

Weight: approximately 170g
