Tension Range: 0~0.2kgf
Tension Range: 0~200gf
Tension Range: 0~1.96N
Tension Range: 0~0.44Lbf
Resolution: 0.001kgf
Resolution: 1 gf
Resolution: 0.001N
Resolution: 0.001Lbf
Accuracy: ±1.0% or better
Unit: kgf, gf, N, Lbf
Measuring Principle: Strain gauge
Measuring Frequency: 16 msec (62.5 samples/sec)
Sensing Roller: Deflection of Sensing Roller (max.) 0.2mm
Overload Capacity: 150% of Full Scale
Temperature Coefficient: Zero: less than +0.3% FS/°C Span: less than +0.01% FS/°C
Display: Blue Back light LCD
Display Update Rate: 0.5, 1.0, 2.0 or 4.0 seconds, dip-switch selectable
Memory System: Current Value, Max. Value, Peak Value, Min Value
Overrange Indicator: Buzzer Alarm
Power Off: 10 Minutes Auto Power Off, Manual Power Off
Data Output: USB, Bluetooth
Roller Material: Stainless Steel (Standard); Plastic (Optional)
Maximum Speed: 2000 m/min
Operation Temperature: 0~40°C (32~104°F)
Operation Humidity: <80%
Power Supply: 4 x 1.5V AAA UM-4 Battery
Size: Main Unit: 140 x 70 x 31mm (5.5 x 2.8 x 1.2"); Sensor: 102 x 81 x 34mm (4.0 x 3.2 x 1.3")
Weight (Including Battery): 400g (14.11oz)
Standard Accessories: Main Unit; Sensor; Carrying Case; Operation Manual
Optional Accessories: USB Cable & Software ; Bluetooth Adapter & Software
