Motor design (rotation): EC permanent magnet synchronous motor
Motor designs (lift):
Stepper motor (upper drive)
Moving magnet linear drive (lower linear drive)
Displacement transducer design: High-resolution optical encoder (upper drive)
Force capacity (lift drive): -50 N to 50 N
Force capacity (linear drive): 0.0005 N to 40 N
Displacement (linear drive): 0.01 µm to 9400 µm(1)
Minimum torque (rotation): 1 nNm
Minimum torque (oscillation): 0.5 nNm
Maximum torque: 230 mNm
Minimum angular deflection: 0.05 µrad
Frequency (linear drive): 0.001 Hz to 100 Hz
Frequency (upper rotational drive): ~10^-8 Hz to 100 Hz(2)
Maximum temperature: 1000 °C(3)
Minimum temperature: -160 °C(4
Heating rate (max.) : Up to 60 K/min(5)
Cooling rate (max.): Up to 50 K/min(5)
Humidity 5 % RH to 95 % RH(6)
Dimensions (W x H x D): 444 mm x 753 mm x 586 mm
Weight: 48 kg (61 kg with optional linear drive)
Performs torsion, tensile, compression, bending, shear, friction, peel, and other tests : yes
Toolmaster™ (measuring geometries and accessories, storing of zero-gap) (US Pat. 7275419. 2004): yes
QuickConnect coupling for measuring geometries (one-hand operation, screwless) : yes
Specimen protection: yes
Auto-positioning: yes
Camera option : yes
Collision mitigation : yes
1) In oscillation, a maximum displacement of ± 4500 μm.
2) Minimum frequency is a theoretical value (duration per cycle = two years).
(3 In combination with CTD 1000.
4) In combination with CTD 600 MDR and low-temperature option.
5) Depending on temperature device used.
6) In combination with CTD 180 HR and humidity option.
