Size: 142 x 55 x 40mm
Probe: Type: Inductive Stylus radius: 5μm Angle: 90° Material: Diamond
Accuracy: ±10%
Power supply: Built-in 800mAh rechargeable Lithium ion battery
Measuring force: 4mN
Measuring range: X axis: 17.5mm / 0.69" Z axis: 160μm / 6300μin
Measuring speed: 0.135, 0.5, 1mm/s, 1mm/s (return)
Resolution (Ra): 0.001μm
Sampling length: 0.25, 0.8, 2.5mm
2.5-inch color screen, provide high brightness, wide viewing angle.
Display full information, intuitive and graphical displays all parameters.
DSP chip control and data processing, high speed, low power consumption.
4 profile filter: Gauss, RC, PC-RC, D-P.
Multi parameters: Ra, Rz, Rq, Rt, Rp, Rv, R3z, R3y, Rz (JIS), Rs, Rsk, Rsm, Rku, Rc, Ry, Rmax, Rmr, Rpc
Complies standards: ISO, DIN, ANSI, JIS
Data output to excel via SPC cable or bluetooth connection.
Support Bluetooth printer.
Large capacity data storage, can store 100 item of raw data and measured profile.
With automatic sleep, automatic shutdown power-saving features.
