Medium temperature range: -30 ° C to 150 ° C
Ambient temperature: -20 ° C to 80 ° C
Ambient humidity: ≤ 95% RH
Measured medium: liquid, powder or granular solid
Measured medium density: solid ≥ 0.1g/cm3, liquid ≥ 0.7g/cm3
Measured solid particle size: ≤ 10mm
Maximum liquid viscosity: <1000mm2 / s
Measured medium repose angle: ≥ 200
Pressure range: ≤ 1MPa ※ shell material: die-casting aluminum alloy
Fork material: 1Cr18Ni9Ti
Shell protection: IP65 ※ connection: 1 “NPT thread / flange (two ways)
Electrical parameters:
1: Supply voltage: 24 V DC; 220V AC 50Hz
2: Output signal: relay output double-pole double-throw (DPDT) contact capacity: 8A 220V AC 4A 24V DC
3: Power consumption: ≤ 2W
Read the documentation carefully before ordering
