■ Xenon Lamp：One 1.8KW xenon lamp （imported from America）
■ Lamp Lifetime: Near 1.500 hours
■ Filter：IR Window glass filter（Also can choose daylight filter or extended UV filter）
■ Exposure Area：2.200 cm2 (12 pcs standard sample holder, can put 23 pcs samples of 137mm×45mm size)
■ Controlling irradiance point：340nm or 420nm or 300nm～400nm420nm or 300nm～800nm
■ Adjustable Irradiance Range：30W/m2～90W/m2（300nm～400nm）or 0.5 W/m2～1.35 W/m2（@ 420nm）or 0.3 W/m2～0.75 W/m2（@ 340nm）or 320W/m2～850W/m2（300nm～800nm）
■ Adjustable Black Panel Temperature Range：RT～100℃
■ Adjustable Working room Temperature Range：RT～62℃
■ Adjustable relative humidity of working room：10%～75%（Light）；10%～95%（Dark）；
■ Overall Size：860×800×1770mm (L×W×H)
■ Net Weight：200KG
■ Power Supply：AC 380V（Three-phase four-wire system）/ 50HZ；Max. Current 16 A
■ Max. Total Machine Power：5.5 kW
■ Requirements of Compressed air：Clean，oilless compressed air with 0.5MPa pressure，Max. air supply is near 60L/min. Average air consumption is 10L/min～30L/min（Depends on testing standard）
