Inner size: 1170×450×500(L×W×H)MM
Outside dimension: 1300×550×1480(L×W×H)MM
Whole chamber materials: 304# stainless steel
Temperature range: RT+10℃~70℃
Temperature uniformity: ±1℃
Temperature fluctuation: ±0.5℃
Temperature control: PID SSR control
Humidity range: ≥90%RH
Controller: Korean TEMI 880 programmable controller, touch screen display
Control mode: Balance temperature humidity control (BTHC)
Communication port: Be able to control the machine via computer using TEMI control software through RS-232 port on the machine
Test cycle setting: Illumination, condensation and water spray test cycle is programmable
Distance from specimen to lamp: 50±3mm (adjustable)
Center distance between the lamps: 70mm
Lamp power & length: 40W/Piece, 1200mm/Piece
Lamps amount: 8 pieces
Lifetime of lamp: 1600Hours
Irradiance: 1.0W/m2
Wavelength of ultraviolet light: UVA is 315-400nm, UVB 280-315nm optional
Effective irradiation area: 900×210mm
Irradiation black panel temperature: 50℃~70℃
Standard specimen size: 75×290mm/24 pieces
Water depth for water channel: 25mm, automatically control
Testing time: 0～999H, adjustable
Power: AC220V/50Hz /±10% 5KW
Protection: Overload short circuit protection, over temperature protection, water lacking protection
Corresponding standard: ASTM D4329, D499, D4587, D5208, G154, G53；ISO 4892-3, ISO 11507；EN534；EN 1062-4, BS 2782；JIS D0205；SAE J2020
