Operating Parameters & General
Maximum Input Voltage (CAT I): 18 kV (DC + ACpk), 12 kVrms AC
Maximum Loading Current: 90 µA
Division Ratio: 1000:1
Bandwidth: DC to 150 MHz
Compensation Range: 10 pF to 35 pF
Temperature Coefficient: ≤200 ppm/ºC
Input Resistance: 200 MΩ
Input Capacitance: 1.5 pF
Rise Time: 2.4 ns
Signal/Noise:
>60 dB @ 1 kHz
>50 dB @ 1 MHz
Accuracy:
DC Volts: ≤3%
AC Volts : ≤3% at 1 kHz
Cable Length:6.6 ft (2 m)
Designed for Use in: Pollution Degree 2
Operating Environment: 14ºF to 131ºF (-10ºC to 55ºC)
Storage Temperature: -4ºF to 158ºF (-20ºC to 70ºC)
Humidity: ≤85% RH at 95ºF (35ºC)
Dimensions: 3.1 × 3.1 × 12.6 in (8 × 8 × 32 cm)
Weight: 1.0 lbs (460 g)
