- Number of channels: 1
- Output specifications
+ Output voltage: 0–40 V
+ Output current: 0–150 A
+ Output power: 5000 W
+ Efficiency: 87%
- Noise & ripple
+ Voltage P-P: 68 mV
+ Voltage RMS: 9 mV
+ Current RMS: 180 mA
- Slew rate
+ Voltage: 0.001 V → 8 V/ms
+ Current: 0.001 A → 3 A/ms
- Input specifications
+ AC input voltage range:
1 phase 200–240Vac ±10% (phase–neutral)
3 phase 200–240Vac ±10% (line–line, Delta 4-wire connection)
3 phase 380–400Vac ±10% (Wye 5-wire connection)
+ Frequency range: 47–63 Hz
+ Power factor: 0.98
- General specifications
+ Control interfaces
Standard: Ethernet, USB
Optional: GPIB, CAN FD / RS232, APG, parallel & series control
+ Programming function
Programs: 10
Sequences: 100
Step time: 10 ms – 65535 s
+ Voltage drop compensation
5 V (output voltage 40–600 V)
10 V (output voltage 800–1200 V)
+ Operating temperature
0–40°C: 100% full load operation
41–50°C: derating to 85%
+ Dimensions: 43.5 × 428 × 620 mm
- Standard accessories: Main unit
