- Bidirectional source/load specifications
+ Source/sink voltage: 650V / 1300V
+ Source/sink current: ±120A / ±60A (650V / 1300V)
+ Source/sink power: ±30000W
+ Minimum load voltage (at max current): 35V / 70V
- Stability
+ Line regulation
Voltage: ±0.01% F.S.
Current: ±0.05% F.S.
+ Load regulation
Voltage: ±0.04% F.S.
Current: ±0.1% F.S.
- Measurement
+ Voltage measurement
Range: 650V / 1300V
Accuracy: ±(0.02% + 0.02% F.S.)
+ Current measurement
Range: ±120A / ±60A
Accuracy: ±(0.04% + 0.04% F.S.)
- Response time
Rise time (full load): 20 ms
Rise time (no load): 10 ms
Fall time (full load): 20 ms
Fall time (no load): 10 ms
- Drift
+ 30 minutes
Voltage: 0.04% Vmax
Current: 0.06% Imax
+ 8 hours
Voltage: 0.02% Vmax
Current: 0.04% Imax
- Temperature coefficient
Voltage: 0.04% Vmax / °C
Current: 0.06% Imax / °C
- Input specifications
+ AC input: 3-phase, 3-wire + protective earth (no neutral)
3-phase 380Vac – 480Vac ±10% (no neutral)
+ AC frequency range: 47 – 63 Hz
+ Power factor: > 0.99
- General specifications
+ Maximum remote sense compensation: 2% full-scale voltage per wire (4% total)
+ Operating temperature range: 0°C – 40°C
+ Storage temperature range: -25°C – 70°C
+ Dimensions (H × W × D): 177 × 428 × 898.5 mm / 6.97 × 16.85 × 35.37 inch
+ Weight: 61 kg / 135 lbs
- Standard accessories: Main unit
