User Interface: In-Sight Explorer EasyBuilder, Cognex VisionView PC Software, and VisionView 900 HMI touchscreen panel
1/3" CMOS Imager: Monochrome and Color
S-Mount/M12 Lenses: Standard: Autofocus (liquid lens) 6.2 mm or manual focus 8 mm / Optional: Manual focus 3.6 mm, 6 mm, 12 mm, 16 mm, 25 mm
Image Modes: 640 x 480 (standard)
Lighting: Standard: Diffuse white LED ring light / Options: Red, blue and IR LED ring lights and lens filters, and polarized light cover
Maximum Acquisition Speed: 40 fps
Relative Processing Speed: 1x
Location Tools: Pattern
Data Output: Pass / Fail
General Protocols: TCP/IP, UDP, FTP, Telnet, RS-232C
Industrial Protocols: OPC UA, EtherNet/IP with AOP, PROFINET Class B, iQSS, Modbus TCP, SLMP/SLMP Scanner, CC-Link IE Field Basic
Connectors: (1) Industrial M12 Ethernet, (1) M12 Power & I/O
Inputs & Outputs: (1) Acquisition trigger, (1) General purpose input4, (4) General purpose outputs4
Dimensions: In-line configuration: 43.1 mm (1.69 in) x 22.4 mm (0.88 in) x 64 mm (2.51 in) / Right-angle configuration: 43.1 mm (1.69 in) x 35.8 mm (1.40 in) x 49.3 mm (1.94 in)
Weight: 142 g (5 oz)
Material and Protection: Painted aluminum, IP65-rated housing
Power: 24 VDC +/- 10%, <3.0 W or Class 1 Power over Ethernet (PoE)
PoE Configuration Available: No
Temperature: 0 °C to 40 °C (32 °F to 104 °F)
