Max. Capacity: 200 kN
Units: Force: gf, kgf, lbf, N, kN, ozf, tonf(SI), ton(long), tonf(short); Pressure: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force Precision: 1/100,000
Force Resolution: 31 bits
Test stroke: 1100 mm (w/o grip)
Stroke resolution: 0.0001mm
Space between columns: 550mm (680mm,800mm optional)
Speed range: 0.0001 ~ 330 mm/min
Speed accuracy: High speed mode: 0.02 ~ 330 mm/min; Low speed mode: 0.0001 ~ 1 mm/min
PC-Port: RJ45(TCP/IP)(Connect software optional)
Data sampling rate: 1200Hz (Max.)
Hardware safety protection: upper limit, lower limit, emergency stop
Motor type: Servo Motor
Power Supply: 3 phase 200~240 VAC，20 A
Dimension: 145x66x235cm
Weight: 1250 kg
Option:
- Display panel: EM2FTP-001 or Software: SM2F0-04
or all (nessesary)
- Long
extensometer QC-557
- Grips (nessesary)
