Comet M1300 Ethernet Multilogger - universal datalogger with 4 inputs (AC adapter 230Vac/5Vdc)

DC voltage:

Measuring range: 0 to 10 V

Accuracy: ±10 mV

Resolution: better than 100 µV

DC current:

Measuring range: 0 to 20 mA

Accuracy: ±20 µA

Resolution: better than 0.1 µA

Binary input:

Input voltage for level “switched on”: <0.4 V/> 2 V

Minimum/maximum input voltage: 0 V/+30 V DC

Impedance of the “switched on”: < 10 kOhm/> 300 kOhm

Counter input:

Range of counter: 24 bit (16 777 215) the counter overflow can be allowed

Maximum input frequency: 200 Hz

Operating temperature: -10 to +60 °C

Channels: 4x binary, counter, voltage and current input

Memory: 1 000 000 values (noncyclic record), 600 000 values (cyclic record)

Recording interval: 1s to 24 hours

Display and alarm refresh: each 10 s

Recording mode: noncyclic - data logging stops after filling the memory

cyclic - after filling memory oldest data is overwritten by new

Available temperature units: degrees Celsius, degrees Fahrenheit

Communication interface Ethernet, USB, RS232

Ethernet communication protocols: WWW, SNMPv1, XML, DATALINK

Alarm protocols: E-Mail

Power: AC adapter 230Vac/5Vdc (neccessary for Ethernet interface)

Protection class: IP20

Dimensions (without connectors): 178 x 95 x 37mm, without attached cables

Weight (including batteries): approx. 380 g

Included in delivery:

M1300

Instruction Manual

Traceable Calibration Certificate

3x Rechargeable Battery AA

Power Supply

USB Cable

Wall Holder

FREE FULL VERSION Analytical Software COMET Vision

EXTERNAL PROBES ARE NOT INCLUDED IN DELIVERY
