Sampling Method: Extractive
Alarm Method – Gas Alarm: Beeping with flashing red light and AL icon on the LCD
Alarm Method – Device Error: Beeping with flashing yellow light and error message on the LCD
Power Source:
• Non-rechargeable alkaline AA battery ×4: Toshiba LR6, Panasonic LR6X, Duracell MN1500, Energizer E91 or Varta 4106
• Rechargeable nickel metal hydride AA battery ×4: New Cosmos HR-3UTG
Operating Temperature/Humidity: -20 to +50°C, 95%RH, no condensation
Compliance:
ATEX: Ex II 1G Ex ia d IIC T4 Ga
IECEx: Ex ia da IIC T4 Ga
CE (ATEX, EMC, RoHS, RE and LVD directives)
UL: Class 1, Division 1, Groups A, B, C and D, Class 1, Zone 0 AEx da ia IIC Ga (Other than XP-3380II)
Ingress Protection: IP67
Main Features: Self-diagnosis (sensor error), zero adjustment, battery level indication, flashlight, peak-hold, LCD backlight, audio alarm muting during gas alarm, time indication, alarm test, alarm volume change, audio muting
Dimensions: W91 × H164 × D44mm
Mass: Approx. 460g (including batteries)
Accessories: Gas sampling tube (1m), shoulder strap, drain filter, filter element, alkaline AA batteries (or rechargeable nickel metal hydride AA batteries) ×4, screen protector film ×3
Target Gas 1: Combustible gas / Solvent gas
Detection Principle: Catalytic
Measuring Range (Reference Indication): 0–5000ppm or 0–10000ppm (5001–5500ppm or 10001–11000ppm)
Accuracy: ≤10%F.S.: ±1%F.S.; >10%F.S.: ±5%F.S.
Resolution: 1ppm
Alarm Set Value: 250ppm or 500ppm
Response Time: T90: 30 seconds
Target Gas 2: Oxygen
Detection Principle: Galvanic cell
Measuring Range (Reference Indication): 0–25vol% (25.1–50.0vol%)
Accuracy: ±0.3vol%
Resolution: 0.1vol%
Alarm Set Value: 18vol%
Continuous Operation Time: Approx. 15 hours
