Capacity: 155 Lit
Dimension(w x d x h):
+ Interior(mm): 550 x 480 x 600
+ Exterior(mm): 718 x 777 x 947
Heater Power: 1.6 kW
Temp.Range: Room Temp +5°C to 250°C
Temp.Fluctuation: ±0.3°C at 100°C, ±0.5°C at 150°C
Temp.Variation: ±1°C at 100°C, ±2°C at 150°C
Temp.Sensor: PT 100
Control Resolution: ±0.1°C
Heat-up Time: 25 min. to 100 °C, 40 min. to 150°C
Recovery Time (Door open 30 sec): 6 min. to 100°C, 6 min. to 150°C
Controller: Smart Lab™ Controller
RS232 Port: Available to connect with PC
Display: 4" Full Touch Screen TFT LCD
Timer: 99hr 59 min (delay/continuous function)
Storage: Temperature and Timer setting values
Material:
+ Internal: Stainless-steel(#304), Corrosion Resistant
+ External: Powder Coated Steel
+ Insulation: Glass Wool
Shelf(included):
+ 2 Wire shelf
+ Load per Stainless-steel Wire Shelf: 16 kg
Ventilation: (2ea) Ventilation hole with Stainless-steel Cap, Hole Diameter 40mm
Circulation: Forced-air Type
Safety device: Over Temp. and Over Current Protector, Sensor Error Detector
Alarm: Error Status and Timer-end
Net Weight(kg): 78
Packing size(w x d x h)(mm): 808 x 884 x 1133
Gross Weight(kg): 92
Power Consumption: 1566 W
Energy Consumption at 100°C: 204 Wh
Energy Consumption at 150°C: 398 Wh
Electrical Reqts: 230V, 50/60Hz
Spare Stainless-steel Wire Shelf
DH.W0F11050 Wire Shelf, for 50 Lit, "OFS050", w340 x d310mm
DH.W0F11105 Wire Shelf, for 105 Lit, "OFS105", w455 xd375mm
DH.W0F11155 Wire Shel , for 155-/305-Lit, "OFS155", w520 x d440mm
