Instrument Type:Barium coated sphere with xenon flash lamp, Diffuse illumination, 8º viewing in conformance with CIE publication No. 15.2 Colorimetry
Light Source:Pulsed xenon, filtered to provide D65 illumination including UV component.
Sphere Diameter:Diameter 152 mm / 6.0 inches, Barium coated
Wavelength Range:400 – 700 nm
Reporting interval:10 nm
Photometric range:0 to 200%
Spectral Analyzer:Hyperspectral imaging assembly with 31 narrow bands covering 400 to 700 nm. The imaging is with a scientific 90 db camera with a sCMOS sensor.
20 read repeatability on white tile (CIELAB) (1):0.03 dE (max)
Inter-instrument agreement: reflectance measurements (CIELAB) (1,2 & 3):0.25 (max)* 0.15 (avg)*
Lens:50 mm, fixed focus
Aperture Plates:Square. 25 mm illuminated/ 22.7 mm viewed
Automated, adjustable UV calibration:Yes
UV cutoff filters:400 nm; 420 nm; 460 nm
Functional Operating Environment (2):Temperature: 10°C to 35°C, Recommended Temperature: 23°C +/- 2°C, Maximum Relative Humidity: 20%-85% non-condensing, Recommended Relative Humidity: 50% +/-15% non-condensing, Altitude: Up to 2,000 meters, Do not store above 140°F (60°C),
Vertical Mount:Yes
Physical Specifications:
Power Requirements:Input Voltage: 100-240VAC, Frequency: 50/60 Hz, 150 VA Peak
Power Consumption:150VA
Weight:146 lbs. (66.22 kgs)
Dimensions:Instrument body (top section): Depth (front to back) 13.5” (34.29 cm) Width 15” (38.1 cm) Instrument base (stand): Depth (front to back) 19” (48.26 cm) Width 19.5” (49.53 cm) Instrument standing height: Base feet to top of instrument 31.75” (80.64 cm)
Additional Technical Specifications:
Data Interface:Ethernet
Other Interface(s):HDMI (Video)/USB:2.0 (Keyboard,Mouse)
Image Resolution:821 x 821
Effective Pixel Size:27.6 micrometers
Output:QTX2, Reflectance Hypercube, QTX
Additional Functional Data :
Software Connection:Tools SV
