Max. Operating Current（A）: 3000A
Max. Instantaneous Current(A): 4000A
Temp. Range: Ambient Temperature
Inner Resistance: ＜1mΩ,＜5mΩ,＜10mΩ,＜20mΩ,＜50mΩ,＜100mΩ(Optional)
Control Mode: PLC Touch Screen + Computer remote control + Remote controller
Overall Dimension: W700xD1050xH1830mm
Explosion proof Chamber Dimension: 800 X 800 X 800mm,1000 X 1000 X 1000mm (Optional)
Voltage Measurement Range: 0~500V
Short Circuit Response Time: ≦20ms
Data Interface: USB, Data card, etc.
Data Acquisition Module: Independent remote acquisition, multi-voltage/temperature/current acquisition channels ensure data accuracy. Acquisition frequency 100HZ
Short Circuit Mode: Pneumatic + vacuum arc extinguishing
Safety Device: Electric leakage, over current protection ,smoke alarm device, abnormal sound light alarm.
Testing Fixture: Customize according to actual testing condition
Power Supply: 220V 50HZ
