Action: Single
Air Connection: 1/4 in NPT Female
Air Consumption: 0.1 SCFM
Air Flow, Max: 28 SCFM
Air Supply Pressure, Max: 101 psi
Air Supply Pressure, Min: 20 psi
Compliance: CE
Conduit Connection: 1/2 in NPT female
Electrical Connection: Screw Terminal
Enclosure Material: 316 Stainless Steel
Enclosure Ratings: IP66
Gauge Port Size: 1/8 in NPT female
Hysteresis: 1% FS
Impedance: 250 ± 15 Ω
Input Type: mA
Lever Type: NAMUR
Linearity: ± 2% FS
Operating Temperature, Max: 158 °F
Operating Temperature, Min: -4 °F
Pressure Type: Gauge
Repeatability: ± 0.5% FS
Sensitivity: ± 0.5% FS
Stroke: 0 to 90°
Weight: 6.2 lb
