Weight: 2 oz
Accuracy: ± 0.1 % + 2 count
Mounting: Snap-In Bezel Mount
Polarity: Automatic, positive implied, negative polarity indication
Impedance: 390 Ω
Input Type: Voltage
Display Type: LCD
Warm Up Time: 10 min
Sampling Rate: 3 Hz (3 updates/second)
Supply Voltage: 12 Vdc/24 Vdc
Backlight Power: 24 Vdc @ 35 mA
Span Adjustment: ± 1999 Counts
Number of Digits: 3.5
Decimal Selection: 3-Position, User Selectable
Supply Power Type: DC
Voltage Input Range: 0 to 200 mVdc, 0 to 5 Vdc, 0 to 10 Vdc
Display Segment Color: Green
Electrical Connection: Screw Terminal
Display Segment Height: 11.6 mm (0.45 in)
Storage Temperature, Max: 158 °F
Storage Temperature, Min: -4 °F
Number of Display Segments: 7
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 32 °F
Front Panel Display Readings: °F, °C, %, psi
Zero Setting Adjustable Range: ± 1999 Counts
