Weight: 2.7 oz
Compliance: CE, cULus
Input Type: Thermocouple, RTD, DC Voltage or DC Current
Output Note: Relay: 3 A @ 250 VAC resistive
Memory Backup: Non-Volatile
Switch Rating: 3 A @ 250 Vac
Control Output: SPST Relay
Data Interface: RS-485 Modbus ASCII/RTU
Supply Voltage: 24 Vdc
Controller Type: Master
Output Type (A): Current
Output Type (B): Relay
RTD Input Range: JPt 100: -4 to 752°F; Pt 100: -328 to 1562°F; Ni 120: -112 to 572 °F; Cu 50: -58 to 302 °F
Power Consumption: 3 W
Supply Power Type: DC
Voltage Input Range: 0 to 5 V, 0 to 10 V
Current Output Range: 4 to 20 mA
Input Control Signal: 0 to 20 mA
Mounting Orientation: DIN Rail
Temperature Sensor Type: RTD or Thermocouple
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 32 °F
Thermocouple Input Range Note: Type K: -328 to 2372°F; Type J: -148 to 2192°F; Type T: -328 to 752°F; Type E: 32 to 1112°F; Type W: -328 to 2372°F; Type R: 32 to 3092°F; Type S: 32 to 3092°F; Type B: 212 to 3272°F; Type L: -328 to 1562°F; Type U: -328 to 932°F
