Brinell Scale:HBW2.5/62.5 HBW2.5/187.5 HBW5/62.5 HBW5/125 HBW5/250 HBW5/750 HBW10/100 HBW10/1500 HBW10/1000 HBW10/250 HBW10/500 HBW10/3000
Load Kgf(N):62.5 (612.9), 100 (980.7), 125 (1226), 187.5 (1839), 250 (2452), 500 (4903), 750 (7355), 1000 (8907), 1500 (14710), 3000 (29420)
Load accuracy:0.1%. Better than normal Brinell hardness tester 1% (above 1000Kgf)
microscope magnification:20X (option: 10X, 15X，30X)
Min measuring unit:0.625µm( option:0.3125µm)
Dwell time:5-60s
Hardness range:8-650HBW
Turret:Automatic
Data output:LCD display, USB interface saved in USB flash disk
Executive Standard:ISO 6506, ASTM E10-12, JIS Z2243, GB/T 231.2
Test space:200*135mm (H*D)
Power supply:AC220+5%,50~60Hz
Overall Dimension:550*210*750mm
Net weight:About 90kg
Standard Accessories:
Measuring microscope 20X1
Diameter 2.5mm Hard alloy indenter1
Accessories box1
Diameter 5mm Hard alloy indenter1
Anti dust cover1
Diameter 10mm Hard alloy indenter1
V-type working table1
Medium working table1
Hardness block3
Large working table1
USB flash disk1
Quality certificate1
Manual book1
