Test Force (Kg):1, 2.5, 5, 6.25, 10, 15.625, 25, 30, 31.25, 62.5 Total 10 types
Ball Diameter (mm):5mm，2.5mm，1mm
Test force:Automatic unloading test force
Test force dwell time:0 ~ 60S (one unit per second)
Objective magnification:5X, 10X
Illumination:Exterior lighting, each lens comes with a light source
Eyepiece magnification:10 × (automatic digital encoder)
Minimum test unit:0.25μm
Data correction:Each lens, automatic correction respectively
Hardness test range:4-650HBW
Test space:180*160mm (H*D)
Data output:U disk
Power supply:AC220V+5%，50-60Hz
Dimensions:720*190*650mm
Weight:40Kg Standard
Accessories：
Digital measuring eyepiece1
Brinell Hardness block2pcs
Power cord1
Large, medium, V-type testing bench1 Each
USB flash disk1
Fuses2pcs
Manufacturer certificate1
Operation Instruction1
