Resolution:0.1um/0.01mil
Calibration:Points: ZERO/50/100/250/500/1000um
Units:um, mil
minimum curvature radius convex: 1.5mm
minimum curvature radius concave: 25mm
minimum measuring area: Diameter: 6mm
Power:4 x AAA batteries
Operation EnvironmentTemperature:0~40℃(32~104℉) Humidity: 20%~90%RH
Size:155mm x 62mm x 35mm (6.10” x 2.44” x 1.38”)
Weight: 125g(4.41oz)
Prob type F:
Principle:Magnetic Induction
Range:0~1300um 0~51.2mil
Accuracy:±(2.5%+1um) ±(2.5%+0.04mil)
minimum thickness of substrate:0.5mm(0.02”)
Prob type N:
Principle:Eddy Current
Range:0~1300um 0~51.2mil
Accuracy:±(2.5%+1um) ±(2.5%+0.04mil)
Resolution:0.1um/0.01mil
minimum thickness of substrate:0.3mm(0.012”)
Standard delivery:
Main unit1
Probe (Fe & NFe integrated)1
Calibration piece of pre-coated metal sheets2
Calibration piece of foils5
AAA battery4
Operating manual1
Warranty card1
Instrument case1
