Calibration:Points: ZERO/50/100/250/500/1000um
Units:um, mil
Minimum curvature radius convex: 1.5mm
Minimum curvature radius concave: 25mm
Minimum measuring area: Diameter 6mm
Power:One 9V battery
Operation Environment:Temperature:0~40℃(32~104℉) Humidity: 20%~90%RH
Size:130mm x 62mm x 32mm (4.88” x 2.44” x 1.26”)
Weight:100g(3.53oz)
Probe F
Principle:Magnetic Induction
Range:0~1300um 0~51.2mil
Accuracy:±(3%+2um) ±(3%+0.08mil)
Resolution:0.1um/0.01mil
Minimum thickness of substrate:0.5mm(0.02”)
Probe N
Principle:Eddy Current
Range:0~1300um 0~51.2mil
Accuracy:±(3%+2um) ±(3%+0.08mil)
Resolution:0.1um/0.01mil
minimum thickness of substrate:0.3mm(0.012”)
