Measuring Range:1.0~6000mm
Resolution:0.01mm(<100mm) 1mm(>100mm)
Velocity:500~20000m/s 20 fixed velocity
Delay:-20~3400us /resolution : 0.1us
Probe Delay:0~99us /resolution: 0.01us
Linear Error:Horizontal error≤0.1% Vertical error≤3%
Dynamic Range:≥36dB
Sensitivity:≥64dB 200mmФ2 flat-bottomed hole
Matched Damp:50/150/400Ω
Measuring mode:Peak/Verge
Detector Pattern:0~110dB 0/0.1/0.2/0.5/1/2/6/12/ RF/Full-Wave/Positive/Negative/ half-wave
Bandwidth:0.3~1/0.5~4/2~15MHZ
Screen Update Rate:≥60Hz
Alarm:Independent logic gate alarm, alarm threshold thickness measurement
Sluice gate:Two Separated Gate A/B
Measured value display:5 measured value display area, where a main display area, Selectable measurement value content SA/SB/DA/DB/PA/PB/A%A/A%B/dBtA/dBtB/dBrA/dBrB/SBA/DBA/PBA/LA/LB
Working Environment:Temperature：-20℃~70℃ Humidity：5%～90%
Dimension:180×150×50mm
Weight:1.0 Kg（including battery pack）
