Keys Menu: Yes
Data Store: 270
Probe: DL
Testing Block: Optional
Hardness Standards: HL, HV, HRA, HRC, HRB, HB, HV, HS
Applicable materials: Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, cast aluminum alloy
Impact Direction: 360º
Testing direction:Highly accurate in any impact direction
Testing Range:(170-960)HLD,(17.9-69.5)HRC,(19-683)HB,(80-1042)HV,(30.6-102.6)HS, (59.1-88)HRA, (13.5-101.7)HRB
Hardness Standards:HL, HV, HRA, HRC, HRB, HB, HV, HS
Accuracy:HLD: ±0.5% (800HLD)
Repeatability Value:HLD: 0.8% (800HLD)
Resolution:128×64 OLED display
Dimensions:148mm×40mm×30mm
Power Supply:Rechargeable lithium battery
Working Hours:About 10 hours
Working Conditions:Operating temperature: 10-50 c; Storage temperature: -30 ℃ -60 ℃; Humidity: 90% max;
Applicable Materials: Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, cast aluminum alloy, copper zinc alloys (brass), an alloy of copper and tin, copper(bronze)
Application:
Bearings and other parts;
Failure analysis of pressure vessel, steam turbine generator group and equipment;
Heavy workpieces;
Mechanical or permanent assembly installed;
The test space is very narrow;
Standard Equipped:
The instrument host 1 pc
The nylon brush 1 pc
Small bearing rings 1 pc
The ABS instrument 1 pc
