Sonic Vibration Oscillator Output Force: 181 kN | 40 k lbf
Drill Head Tilt: Maximum 90 degrees
Pull Up/Down Force in Combination with Sonic: 6000 daN | 13265 lbf
Drill Head Mass: 890 kg | 1962 lbs
Engine: Caterpillar 4 cylinder water cooled, 140 kW | 188 HP
Water Tank: 500 litres | 132 gallon
Fuel Tank: Diesel, 170 litres | 45 gallon
Mast Stroke: 5200/5500 mm | 17’1”/18’0.5”
Maximum Height when Drilling: 7500 mm | 24’7”
Dimensions Folded (L x W x H) approx.: 8850 x 2310 x 2995 mm | 29’ x 7’7” x 9’11”
