Rated input
Voltage: AC 85V~260V
Frequency: 1Φ,50 Hz /60Hz
Power factor: 0.94
Rated output AC mode
Voltage: 1V～150V;2V～300V(150V/300VRange)
Maximum current: 20A/10A(150V/300VRange)
Phase: 1
Power capacity: 2000VA
Peak current: 4 times than maximum current(RMS)
Frequency: 1.0Hz～500.0Hz
Rated Output DC mode ,AC+DC mode
Voltage: 1.4～212V/2.8～424V(150VRange/300VRange)
Maximum current: 10A/5A(150V/300VRange)
Output Power: 1000VA
Voltage output stability: ≤0.1%
Voltage output accuracy: ≤1%setting＋0.2V
frequency stability: ≤0.03%Reading+0.1V
Efficiency of output frequency: ≤0.016%setting＋0.01Hz
THD: ≤0.2%(40.0Hz~65.0Hz);≤0.3% (65.1Hz~500.0Hz)
Transient reaction time: ＜60μs
Load influence: ≤0.2%+0.2V
Power voltage influence: ≤0.1%
Power efficiency: ≥75％
Measurement
Voltage Range / Resolution / Basic accuracy: 75V/150V/300V / 0.1V / ±(0.2%Reading+0.2%Range +1digit)
Current Range / Resolution / Basic accuracy: 1A/2A/5A/10A /20A / 0.001A(0～9.999A);0.01A(10A~99.99A) / ±(0.2%Reading+0.2%Range +1digit)
Power Resolution / Basic accuracy: 0.1W(0.1W～999.9W);1W(more than 1000W) / ±(0.3%Reading+0.2%Range +1Digit)
