EXFO FTBx-2250 Broadband Source

SLED SOURCE SPECIFICATIONS

Mean wavelength (nm): 1550 ± 25

Output power (dBm): ≥ 3

Peak spectral density (dBm/nm) : –23

Minimum spectral density (dBm/nm) : –27

Total power stability (dB) : 15 min: ±0.017;  8 hours: ±0.02

Spectral density stability (dB) :  15 min: ±0.035 (typical); 8 hours: ±0.046 (typical)

Ripple (dB) : 0.35

Fiber type (µm) : 9/125

GENERAL SPECIFICATIONS

Size (H x W x D): 25 mm x 159 mm x 175 mm (1 in x 6 1/4 in x 6 7/8 in)

Weight: 0.35 kg (0.77 lb)

Temperature

Operating: 0 °C to 40 °C (32 °F to 104 °F)

Storage: –40 °C to 70 °C (–40 °F to 158 °F)

Relative humidity: 0 % to 80 % non-condensing

LTB-8 operation: Windows 10

Instrument drivers: IVI Drivers, LabVIEW™ drivers and SCPI commands

Remote control (automation): With LTB-8: GPIB (IEEE-488.1, IEEE-488.2), Ethernet and RS-232
