Output Current: 1A
Output Voltage: 6V
Output Power: 6W
Channels: configurable 6, 12, 18, 24CH for a single unit
CC mode
Range: 0～1A
Design resolution: 0.1mA
Design accuracy (25±3℃): 0.05%+0.05%F.S
Readback resolution: 0.02mA
Readback accuracy (25±3℃): 0.05%+0.05%F.S
Temperature coefficient: ＜25ppm/℃(25±3℃)
CV mode
Range: 0～6V
Design resolution: 0.1mV
Design accuracy (25±3℃): 0.01%+0.01%F.S.
Readback resolution: 0.1mV
Readback accuracy (25±3℃): 0.01%+0.01%F.S.
Temperature coefficient: ＜25ppm/ ℃(25±3℃)
Voltage ripple (20Hz～20MHz): 1mVrms
Current ripple (20Hz～20MHz): 1.2mArms
Voltage rise time (no load): ＜100μs (time for 10%～90% change)
Voltage rise time (full load): ＜100μs (time for 10%～90% change)
Voltage fall time (no load): ＜100μs (time for 10%～90% change)
Voltage fall time (full load): ＜100μs (time for 10%～90% change)
Transient response: ＜50μs
Withstand voltage (output): 1500VDC
Withstand voltage (channels): 1500VDC
Programming response: ＜5ms
Communication: LAN/RS485
Input AC Voltage: 220VAC±10%
Input AC Current: ＜1A
Size: 88.1 * 482.6 * 521.4 mm (Height*Width*Depth)
Weight: 10Kg
