Test voltage (DC): 250V, 500V, 1000V, 2500V, 5000V
Bar graph range: 0 to 1 TΩ
Insulation test voltage accuracy: -0%, +10% at 1 mA load current
Induced AC mains current rejection: 2 mA maximum
Charging rate for capacitive load: 5 seconds per μF
Discharge rate for capacitive load: 1.5 s/μF
Leakage current measurement:
Range: 1 nA to 2 mA
Accuracy: ±(5% + 2 nA)
Capacitance measurement
Range: 0.01 μF to 15.00 μF
Accuracy: ±(15% rdg + 0.03 μF)
Timer
Range: 0 to 99 minutes
Resolution setting: 1 minute
Resolution indication: 1 second
Display: 75 x 105 mm
Power: 12 V lead-acid rechargeable battery, Yuasa NP2.8-12
Charger Input (AC): 85 V to 250 V AC 50/60 Hz 20 VA
Dimensions: 269 x 277 x 160 mm (10.6 x 10.9 x 6.3 in)
Weight: 3.7 kg (8.2 lb)
Temperature (operating): -20°C to 50°C (-4°F to 122°F)
Temperature (storage): -20°C to 65°C (-4°F to 149°F)
Humidity: 80% to 31°C decreasing linearly to 50% at 50°C
