1. Voltage measurement :
- Range : 0 V to 28 VDC
- Resolution : 1 mV
- Accuracy : 0.015 % Rdg + 1 counts
2. Current measurement :
- Range : 0 mA to 24 mA
- Resolution : 0.001 mA
- Accuracy : 0.015 % Rdg + 2 counts
- Loop power while measuring mA : 24 VDC
3. Current sourcing :
- Range : 0 mA to 20 mA (optional) or 4 mA to 20 mA (standard)
- Accuracy : 0.015 % Rdg + 2 counts
4. General Specifications :
- Maximum voltage: 30 volts
- Non-operating temperature: –4 °C to 60 °C
- Operating temperature: –10 °C to 55 °C
- Relative humidity: 95 % (10 °C to 30 °C); 75 % (30 °C to 40 °C); 45 % (40 °C to 50 °C); 35 % (50 °C to 55 °C)
- Power: 9 V battery (Source mode: 18 hours; 12 mA into 500 Ω; measure/simulate Mode: 50 hours)
- Size : With holster and Flex-Stand: 76.20 mm (W) x 158.75 mm (L) x 54.61mm (H)
- Weight : With holster and Flex-Stand: 349 g
Includes:
AC70A Alligator Clips
C10 protective yellow holster with Flex-Stand™
Instruction sheet
TL75 safety-designed test lead set
NIST- traceable calibration report and data
