Infrared resolution: 320 x 240 (76,800 pixels)
SuperResolution: 640 x 480
Detector type: Uncooled focal plane infrared detector
Infrared Spectral response: 8 to 14 µm
Field of view: 42°: 42° x 32°
IFOV: 2.29 mRad
Minimum focus distance: 0.1 m
Focus system: Manual focus + focus free
Agile Focus: Yes
Digital Zoom: 1-4x
Wireless connectivity: Yes, direct transfer thermal images wirelessly to mobile phones or PCs
Standard software: Fluke Connect Express: Yes, functions such as thermal image analysis, historical trend generation, custom reports, and inspection management supported
Asset tagging: Yes, name thermal images automatically by scanning QR codes or barcodes and save them as asset tags for thermal images
IR-Fusion technology: Blend continuous 0 % to 100 %. 1% step for adding visible details to infrared images
Picture-in-Picture (PIP): Yes
Display screen: 3.5" (8.9 cm landscape) Touchscreen 640 x 480 LCD
Ergonomic design: Designed specifically for one-handed use
Thermal sensitivity: <= 40 mk (0.04 ℃)
Temperature level and span: Smooth auto and manual scaling
Fast auto-rescale in manual mode: Yes
Minimum span (in manual mode): 3 °C
Minimum span (in auto mode): 3 °C
Built-in digital camera (visible light): 13 mp
Frame rate: 30 Hz
Dew point calculation: No
Temperature Measurement:
Temperature span: -20 °C to 600 °C
Temperature range: -20 °C to 150 °C; 0 °C to 600 °C
Accuracy: ±2 °C or 2%, whichever is greater (ambient temperature of 18 to 28 °C)
On-screen temperature correction: Yes, emissivity, background temperature, measurement distance and transmission correction supported
Standard palettes: 10 Gray, Ironbow, High Contrast, Amber, Hot Metal, Blue-Red, Amber Inverted, Gray Inverted, Rainbow, Steps
Spot temperature: Center spot (unmovable)
Auto high/low temperature capture: High and low temperature points marked and tracked automatically
User-definable spot markers: Points: 5; Lines: 5; Areas: 5
Custom temperature difference calculation: 3
3-phase maximum temperature difference calculation: Yes
Image mode: Infrared, visible light, PIP, visible light and infrared fusion
Audible alarm: Alarm objects: highest temperature point, lowest temperature point, center point, custom point or line or area, 3-phase maximum temperature difference, custom temperature difference; Alarm conditions: Above the temperature, below the temperature
Color alarm: Yes, above the temperature, below the temperature, within the temperature span, outside the temperature span
Preset measurement parameters (profile): Up to 50 profiles can be saved
Data Storage and Image Capture:
Storage: Standard with a 64 GB SD card; Expandable up to 1 TB memory size
Image capture, review, save mechanism: One-handed image capture, review, and save capability
Image file formats: JPEG (with temperature data)
Memory review: Yes
Voice annotation: Yes, 60 s maximum audio recording via a Bluetooth Audio Headset
IR-PhotoNotes: Yes. Up to 3 extra visible light images captured can be included in JPEG files
Text annotations: Yes, multiple languages supported
Severity annotations: Yes, annotations for the 4 severity levels: normal, moderate, severe, and extreme
Video recording and formats: Standard video format: mp4
Fully-radiometric infrared data streaming: No
Auto capture (temperature and interval): Yes, user-selectable time interval for capturing images.
Route Inspection Function:
Create and manage inspection routes: Yes, use the Fluke Connect Express software
Start, execute and manage inspection routes: Yes, use the thermal imager
Thermal images classified and archived automatically according to inspection routes: Yes
Automatic reporting and trend summaries: Yes
Battery:
Batteries (field-replaceable, rechargeable): Lithium-ion rechargeable battery
Battery life: >5 hours (Actual life depends on settings and usage)
Battery charging time: < 4 hours to full charge
Battery charging system: Ti SBC3B Two-Bay Battery Charger used or charged via the Type-C interface
External power supply: AC operation through the included power adapter with the output: 15 VDC, 2 A
General Specificiations:
Preset shortcut keys: 6
Laser: Yes
Flashlight: Yes
Type-C interface: Yes, charging and data transfer supported
Operating temperature: -10 °C to 50 °C
Storage temperature: -20 °C to 60 °C， without batteries
Relative humidity: 10% to 95% non-condensing
Safety standards: IEC 61010-1: pollution degree 2
Electromagnetic combability: IEC 61326-1: Industrial Electromagnetic Environment; CISPR 11: Group 1, Class A
Australia RCM: RCM IEC 61326-1
Radio frequency (WIFI and Bluetooth): 2.4 GHz
Radio output power (WIFI and Bluetooth): <100 mW
Laser: IEC 60825-1, Class 2; 650 nm; <1 mW
Drop: Engineered to withstand 2 m drop
Ingress protection: IEC 60529: IP52
RoHS3 Directive: Yes
Other Specifications:
Size (L x H x W): ∼ (26.7 cm x 10.1 cm x 14.5 cm)
Weight (battery included): 950 g
Supported Languages: Simplified Chinese, Traditional Chinese, English, Korean, Japanese
Recommended calibration period: 2 years
Standard accessories: One thermal imager, Two batteries, One 2-Bay Battery Charging Base, One soft bag, One hard case, One SD card, One AC adapter
