Technical parameter of the equipmen
Capacity: 2 m³/h
Recovery pressure: ≤0.05 MPa
1m³ gas recovery time (initial pressure 0.6MPa): ≤3 h/m³
Final pressure: 0~0.8 MPa Adjustable
1m³ gas injection time(initial pressure 133Pa to 0.6MPa): ≤3 h/m³
The time required for 1m³ volume vacuity form 0.1MPa to 133 Pa: ≤1 h
Ultimate vacuum: ≤10 Pa
Gasification way: Electric Heating
Liquefaction way: High pressure condensation liquefaction
Dry filter regeneration mode: Vacuum activation regeneration
External dimensions (including storage tank rack): 1000*800*1500
Working power: (380V-50Hz) 3Phase 4 Wires, or as per buyer's option
Total electrical power: 5 KW
Performance Index
SF6 Gas purity after recovery: 60 PPM
Oil content: 5 PPM
Impurities: 1 μm
Technical Performance
Type: High pressure liquefaction, mobile
Working Environmental Temperature: -10℃~45℃
Recovery: Initial pressure: 0.8
Final pressure: ≤0.03 (Mpa)
Time to recover 1 m³ gas: ≤0.3 (h/ m³)
Filling: Initial pressure: ≤133 (PA)
Final pressure: 0~1 Mpa (adjustable)
Time to fill 1 m³ gas: ≤0.3 (h/m³)
Time for pumping vacuum from 0.1Mpa to 133Pa(h/m³): ≤0.3
Limit vacuum: ≤10 (Pa)
Increasing value in 24 hours for the vacuum keeping at 133PA: ≤400 (Pa)
Gas purity after recovery SF6: Water content: ≤60 (PPM/V)
Oil content: ≤10 (PMM/W)
Storing tank: Dust: ≤1 (μm)
Storage method: Liquid gas
Pressure: 5 (Mpa)
Volume: 110; 200; 300 (L)
Liquid volume: 100; 180; 280 (Kg)
Liquefaction method: High pressure condensing
Vaporization method: Heating with electricity
Dry filter regeneration: Vacuum heating activation regeneration
Power: According to your requirement
Total power: ≤18 (KW)
