Voltage
- Test voltage output (Phase-Neutral): 3*(0V-450V)
- Power of the voltage output: Max.3*20A
- Resolution: 0.01%
- Accuracy: 0.05%
- Stability: 0.02%/120s
Current
- Test current output: 3*(1mA-120A)
- Power of the current output: Max.3*100VA
- Stability: 0.02%/180s
Phase angle
- Range: 0-360°
- Resolution: 0.01°
- Accuracy: 0.2°
Frequency: Resolution: 0.005Hz
Pulse output:
- High frequency output(HF): Multiple constance
- Low frequency output(LF): LF=HF/20000
Pulse input:
- Input channel: 3
- Input frequency: Max.20Hz
Dimension (LxWxH)/ Weight
- Main: 445x180x680mm/46kg
- Auxiliary: 990x630x730mm/100kg
