Calibration: Calibration of spectral radiant power responsivity in A/W in 10nm steps from 400 nm - 1100 nm
Spectral range: 400 nm - 1100 nm radiometric
Typical responsivity:
8.5E-03 A/W @ 630 nm
1.15E-02 A/W @ 900 nm
(attenuation possible)
Measurement ranges:
ISD-3P-Si @ 600 nm
min (0.1 pA): 1.18E-11 W
max (200 µA): 2.35E-02 W
max (1 mA): 1.18E-01 W
ISD-3P-Si @ 900 nm
min (0.1 pA): 8.70E-12 W
max (200 µA): 1.74E-02 W
max (1 mA): 8.70E-02 W
max. Radiant Power (CW): may be limited by max. operation temperature
Max. signal current: 1 mA
Input optics: 5 mm Ø
Sphere diameter: 30 mm
Coating: synthetic ODM98
Sensor: Si photodiode
Spectral range: 400 - 1100nm
Rise time: 0.1 µs
Mounting: M6 thraded hole
Connection cable: coaxial cable 2m Long, with ITT (-4) connector
Temperature range: 5 - 40°C
