Operating AC voltage, V: 100-260
Power frequency, Hz: 48 – 63
Power requirement, VA: 80 max
Max output voltage, kV: Sinusoidal, up to 100 kV RMS
Output voltage measurement tolerance, kV: ±1
Voltage increase rate, kV/s: From 0.5 to 10 kV (Adjustable)
Resolution of output voltage indication, V: 100
High voltage shutoff time after breakdown, μs : 10 max, 4 typical
Measuring cell volume, cm^3: 500
Measurement range of ambient temperature, °C : 0-100
Temperature measurement resolution, °C: 0.1
Integrated printer: yes Operating temperature, °C: 0-50
Storage temperature, °C: From – 20 to + 60
Relative humidity, %: Up to 90 without condensation Dimensions, mm, not more than: 510x300x350
Weight, kg, not more than: 30
