Infrared detector:
Detector type: VOx
Infrared resolution: 256 ×192@12 μm
Wavelength range: 7.5~14μm
Frame rate: 25 Hz
Lens: 3.2 mm 7 mm
Field of view: 25°
Focusing mode: Automatic/Electric
Temperature measurement
Measurement range: -20℃-150℃
Measurement accuracy: ±2°C or ±2% whichever is greater
Measurement: Spot, line, area
Macro function
Magnification: 5X
Observed altitude(mm) 48.75/93.16
Visual range(mm) 20.26×15.2/38.33×28.75
Environmental parameters
Working temperature: -10°C to 60°C
IP rating: IP43
Drop: 1m drop test (without the type-c interface)
Certification CE, FCC, RoHS
Physical parameters
External interface: USB Type-C male
Weight: ≤50g
Size: 59 ×24 ×20 mm
Color: Silver/Grey
Standard: A device, Carrying box, Wrist strap, User manual, Certificate of approval, Macro Lens
