Source:
- Channels: 1
- Max. Range: Digits: 6 1/2
Output: Voltage: ±210V
Current: ±1.05A
Power: 22W
Resolusion: Voltage: 5µV
Current: 50pA
DC voltage measuring range: ±200mV/2V/20V/200V
DC current measuring range: ±1µA/10µA/100µA/1mA/10mA/100mA/1A
Resistance measuring range: 2Ω/20Ω/200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ
Dimensions: 214x86x356.5mm
Weight: 4.8kg
Measurement: DC current, DC voltage, resistance
Storage temperature: -20~70°C
Storage Humidity: <80%
Interface: GPIB, LAN, RS232, USB (TMC)
Supply voltage: 90-264VAC; 50/60Hz
Power consumption; 190W
Included accessories: CD (User manual) x 1, Power cord , Test lead(GTL-207A x 1,GTL-203A x 1, GTL-204A x 1)
Optional accessories: GTL-246: USB Cable (USB 2.0 Type A-Type B Cable,4P)
GTL-258: GPIB Cable, 2000mm
