- Infrared Image
IR Resolution: 256 × 192 (49,152 pixels)
NETD: < 40 mK (@ 25 °C, F#=1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 3.6 mm
F-number: F1.0
Field of View (FOV): 37.2° × 50.0°
Spatial Resolution (IFOV): 3.3 mrad
Min. Focus Distance: 0.3 m (0.98 ft)
Focus Mode : Focus Free
- Image Display
Visual Camera: 1600 × 1200 (2 MP)
Display: 240 × 320 Resolution, 3.2”LCD Screen
Color Alarm: Above alarm
Color Palettes: Basic, Black Hot, White Hot, Fire Detection, Rescue, Hot Area, Cold Area, Building
Image Modes: Thermal/Visual/Fusion/PIP
- Measurement and Analysis
Object Temperature Range: -20°C to 550°C (-4°F to 1022°F)
Accuracy: Max. (± 2°C/3.6°F, ± 2%), for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Measurement Tools: Center Spot, Hot Spot, Cold Spot User-definable: 3 spots
- Data Storage and Communication
Storage Media: Built-in 16 GB flash memory
Image Storage Capacity: Approx. 90,000 Images
- General
USB Interface: USB Type-C
LED Light: Yes
Battery Type: Rechargeable Li-ion battery
Battery Charging Time: Approx. 3 hours fully charged
Battery Operating Time: Approx. 6 hours
Protection Level: IP54
Drop Test Height : 2 m (6.56 ft)
Working Temperature Range: Up to 10 minutes for ambient temperature -10°C to 90°C (14°F to 194°F); up to 2 minutes for ambient temperature -10°C to 115°C (14°F to 239°F)
Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)
Relative Humidity: < 95% non-condensing
Weight : Approx. 380 g (0.84 lb)
Dimension: 221.7 × 73.5 × 123.8 mm (8.73 × 2.89 × 4.87 in)
Tripod Mounting: UNC ¼”-20
