Infrared Image
IR Resolution: 96 × 96 (9, 216 pixels)
SuperIR: 240 x 240 (57,600 pixels)
NETD: < 50 mK (@ 25 °C, F#=1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 to 14 μm
Focal Length: 1.35 mm
F-number: F1.0
Field of View (FOV): 50° × 50°
Spatial Resolution (IFOV): 8.89 mrad
Focus Mode: Focus Free
Distance to Spot Ratio (D:S): 112:1
Min. Focus Distance: 0.1 m (0.33 ft)
Image Display
Visual Camera: 640× 480 (0.3 MP)
Display: 320 × 240 Resolution, 3.5" LCD Touch Screen with auto-rotation
Screen Brightness: Manual
Digital Zoom: 1.0x to 4.0x continuous
Image Modes: Thermal/Visual/Fusion/PIP/Blending
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Measurement and Analysis
Object Temperature Range:-20°C to 350°C ( -4°F to 662°F )
Accuracy: Max (±2°C/3.6°F, ±2%) at ambient temperature 25°C (77°F) and object temperature above 0°C (32°F)
Measurement Tools: Center Spot, Hot Spot, Cold Spot
Level and Span Mode: Auto/Manual/1-Tap Touch-screen
Data Storage and Communication
Storage Media: Built-in 4 GB flash memory
Image Storage Capacity: Approx. 30,000 Images
Annotations: Text note: max. 200 characters
Video Storage Capacity: Approx. 20 hours
Video File Format: MP4 video
General
Wi-Fi: 802.11 b/g/n ( 2.4 GHz )
USB Interface: USB Type-C
LED Light: Yes
Battery Type: Rechargeable Li-ion battery
Battery Operating Time: Approx. 4 hours
Battery Charging Time: Approx. 2.5 hours fully charged
Protection level: IP54
Drop Test Height: 2 m (6.56 ft)
Working Temperature Range: -10°C to 50°C (14°F to 122°F)
Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 218 g (0.481 lb)
Dimension: 138.45 × 85.2 × 23.6 mm (5.45 × 3.35 × 0.93 in)
Tripod Mounting: UNC ¼”-20
