Eyepiece: WF10X(∅20mm)
Objective:
- Plan achromatic PL 4X/0.10
- Plan achromatic PL 10X/0.25
- Plan achromatic PL 40X/0.65(Spring)
- Plan achromatic PL 100X/1.25(Spring, oil)
Digital trinocular:
- Built-in clear color 1/3” CMOS sensor , the dynamic resolution is 1280X1024(UXGA) , USB2.0 White balance: Automatic/Manual.
- System requirement：Microsoft® Windows® XP / Vista / 7 / 8 /10 (32 & 64 bit) OSx(Mac OS X Linux
Focus system: Coaxial coarse/fine focus system, the adjustable tensional control and adjustable up stop, minimum division of fine focusing: 2μm
Nosepiece: Quadruple(Backward ball bearing inner locating)
Stage: Double layer mechanical ( Size:160mmX140mm, Move range: 75mmX50mm)
Abbe condenser: N.A.1.25 Rack & pinion adjustable
Filter: Blue filter; Frosted filter
Collector: With field diagram for halogen lamp
Light source: 6V 20W Halogen lamp with brightness control
